EXTERIOR

Body

Light Emitting Diode (LED) projector headlamps with auto leveling
Auto Headlamps on/off
LED with Daytime Running Lamp (DRL)
Electric side view mirrors with turning lamp
Intermittent front wipers, timing adjustable with washer and Rain Sensor

EXTERIOR DIMENSIONS

Overall length (without number-plate holder) 4,340mm
Overall width (without wheel arch molding) 1,695mm
Overall height (without shark fin antenna) 1,479mm
Wheelbase 2,570mm
Front Thread 1,495mm
Rear Thread 1,485mm
Ground clearance (Unladen) 150mm
Min. Turning Radius 4.9m

Wheels & Tires

Tires 185/60R16 with 16X5.5j aluminum wheels

ENGINE

Engine

Type SKYACTIV-G 1.5 In-line 4 cylinder DOHC 16 valve S-VT
Displacement 1,496cc
Bore x stroke 74,5 x 85,8mm
Compression ratio 13.0:1
Maximum output 82W (111ps) @6,000 rpm
Maximum torque 144Nm/4,000rpm
Fuel tank capacity 44L
Recommended Fuel Type Unleaded 90RON

Drivetrain

Transmission Type 6 Speed Automatic
GEAR RATIOS (:1)
1st 3,529
2nd 2,025
3rd 1,345
4th 1.000
5th 0,742
6th 0,594
Reverse 2,994
Final gear ratio 4,319

Suspension

Type (Front/Rear) MacPherson Strut/Torsion beam Axle

INTERIOR

SEATING & TRIM

6-way Manual adjustable driver seat
4-way Manual adjustable front passenger seat
40/60 Split-fold down rear seats
Steering Wheel Leather
– Audio & bluetooth control switches
– Paddle Shift
– Cruise Control
Leather Shift Knob

INSTRUMENTATION

Active Driving Display (ADD)
Analog Tachometer
Front auto climatic control A/C

AUDIO & INFOTAINMENT

Steering-wheel-mounted audio & bluetooth controls
Wireless smartphone Integration
Wireless Smartphone Charger (Qi)
Mazda Connect with 6 speakers

SAFETY & SECURITY

SAFETY – PASSIVE Standard

Airbags
– Dual front
– Curtain & side
High-mount stop lamp
Side-impact door beams
Collapsible steering Shaft & injury-minimizing brake pedal
Neck injury mitigation front seats
Ring Structure unibody construction SKYACTIV-BODY

SAFETY – ACTIVE Standard

Antilock Brake System (ABS) with Electronic Brakeforce Distribution (EBD) and Brake Assist (BA)
Dynamic Stability Control (DSC) and Traction Control System (TCS)
Hill Launch Assist (HLA)
Rear Parking sensors (Corner & Center)
Back-up monitor (with static line)

SAFETY – i-ACTIVSENSE

Blind Spot Monitoring (BSM)
Rear Cross Traffic Alert (RCTA)

SECURITY

Power door lock with Auto door lock system
Immobilizer & burglar alarm
